SPOT LIGHT MOVABLE
PRODUCT SPECIFICATIONS & APPLICATION
Characteristics
IP rating: IP20
Isolation: Input Output Fully Isolated
Startup: Quick start < 500mS
Protection: Under & over voltage protection
HPF, High brightness, Flicker free
Color & Lighting
LED Colour: 3000K, 4000K, 6500K
Lumens: 110Lm/W
Beam angel: 120˚
CRI: >=80%
Operative conditions
Temperature: Ambient temperature
Humidity: up to 80%
Electrical Parameters
Power Range: 3W, 6W, 9W, 16W, 24W
Input Voltage range: AC 100V…265V
Surge Protection: Up to 2.5kV
Power Factor: >= 0.98
THD: <= 10%
Electrical Connection
Build in Connectors or cable
Input side: Two wire (P~N) for 230V AC
Output side: Connect with led
Controls
Dimming mode: No Dimming
Interface: No Interface
Mechanical Construction
Aluminum Or PC housing with Glass and Reflector
Two spring clamps for conceal fitting
Dimension: Refer TDS
Cutout: Refer TDS
Weight: NA
Applications & Examples
Home, Offices, Schools
Exhibition hall, Showroom
Art gallery
Interier lighting
Hospitality lighting
