WALL WASHER LIGHT
PRODUCT SPECIFICATIONS & APPLICATION
Characteristics
IP rating: IP65
Isolation: Input Output Fully Isolated
Startup: Quick start < 500mS
Protection: Under & over voltage protection
HPF, High brightness, Flicker free
Color & Lighting
LED Colour: 3000K, 4000K, 6500K
LED Colour: Red, Green, Blue, Multi Colour
Lumens: NA
Beam angel: 120˚, 90˚, 60˚
CRI: NA
Operative conditions
Temperature: Ambient temperature
Humidity: up to 80%
Electrical Parameters
Power Range: 18W, 30W, 45W, 60W, 90W
Input Voltage range: AC 100V…265V
Surge Protection: Up to 6kV
Power Factor: >= 0.98
THD: <= 10%
Electrical Connection
Build in Connectors or cable
Input side: Three wire (P~N~E) for 230V AC
Output side: Connect with led
Controls
Dimming mode: Yes
Interface: Yes
Mechanical Construction
Aluminium housing with lens and diffuser
Clamp for fitting
Dimension: Refer TDS
Weight: NA
Applications & Examples
Party plot, Palace, Fort
Historical Site, Statue
Open Theater,Garden
Highrise Building
Bridge, Flyover
