SOLAR INTEGRATED ALUMINUM STREET LIGHT
PRODUCT SPECIFICATIONS & APPLICATION
Characteristics
IP rating: IP65
Startup: Quick start < 500mS
Protection: Battery charging, PV Reverse Voltage,
Battery Reverse Voltage Polarity
Color & Lighting
LED Colour: 6500K
Lumens: 110Lm/W
Beam angel: 120˚
Operative conditions
Temperature: Ambient temperature
Humidity: up to 80%
Electrical Parameters
Power Range: 12W, 18W, 24W
Input Voltage range: DC 12V…24V
Controller: Dusk to Dawn
Controller Effeciency: >=90%
Electrical Connection
Build in Connectors or cable
Input side: Two wire (+ve -ve) for PV Panel
Output side: Connect with Battery and led
Controls
Dimming mode: Yes
Interface: No Interface
Mechanical Construction
Dia cast housing with PV Panel
Adjustable Clamp for fitting
Dimension: Refer TDS
Weight: NA
Applications & Examples
Highway, Street
Garden, Public place
Home, Farms, Resort etc.
